24
Installation
Power/Vac® Metal-Clad Switchgear 5kV & 15kV
01.4IB.67000
Figure 11 Typical Assembly Details
FLOOR CAP
FLOOR
TIE PLATE
AISLE FLOOR
AISLE END
EXTENSION
NUT RETAINER
1/4-20 BOLT X 1LG
WASHER
LOCKWASHER
ASSEMBLY OF
DETAILS A & B
3/8-16 BOLT X 1LG
WASHER
LOCKWASHER
NUT
AISLE FLOOR
AISLE SIDE PANEL
ANCHOR
BRACKET
SHIP IN
PLACE
ASSEMBLY OF
DETAILS C&D
3/8-16 BOLT X 1-1/4 LG
WASHER
LOCKWASHER
METAL CLAD
EQUIPMENT
AISLE FLOOR
ASSEMBLY OF
DETAILS E&F
AISLE END
EXTENSION
METAL CLAD
EQUIPMENT
3/8-16 BOLT X 1 LG
WASHER
LOCKWASHER
NUT
ASSEMBLY OF
DETAILS G&H
3/8-16 BOLT X 1LG
WASHER
LOCKWASHER
NUT
AISLE SIDE PANEL
AISLE END
EXTENSION
ASSEMBLY OF
DETAILS J & K
CAP BUSHING
AISLE ROOF
AISLE ROOF CAP
CHANNEL
ROOF CAP
3/8-16 BOLT X 1 LG
WASHER
LOCKWASHER
NUT RETAINER
AISLE SIDE PANEL
ASSEMBLY OF
DETAILS L & M
APPLY CLEAR SEAL ON
VERTICAL JOINT
METAL CLAD ROOF
GASKET
ANGLE
1/4-20 BOLT
WASHER
LOCKWASHER
(REUSED)
AISLE ROOF
1/4-20 BOLT X 1 LG
WASHER
LOCKWASHER
NUT
ASSEMBLY OF
DETAILS P & N
ROOF AISLE
AISLE ROOF CAP
CLEAR SEAL BEAD
1/4-20 BOLT X 1-1/4 LG
WASHER LOCKWASHER NUT
ROOF PANEL
GASKET
DETAIL R WITH
END CAP REMOVED
ROOF PANEL
REUSE 1/4-20
HARDWARE FROM FIG.3
END TRIM CAP
1/4-20 BOLT X 3/4 LG
WASHER
LOCKWASHER
NUT
DETAILS EE-FF
