Powell Power/Vac - Figure 41 Left Side Racking Rail; Figure 42 Right Side Racking Rail

75 pages

Save Page as PDF

To Next Page

To Previous Page

Operation

Power/Vac® Metal-Clad Switchgear 5kV & 15kV

01.4IB.67000

Figure 41 Left Side Racking Rail

a. Position Indicator

b. Racking Shaft

c. Racking Nut

d. Bearing

e. Rail

f. Slot

g. Notched Sliding Link

h. Detent

i. Bolt

j. Keylock

k. Interference Interlock

Figure 42 Right Side Racking Rail

a. Racking Nut

b. Bearing

c. Jack Screw

d. Rail

e. Operating Cam

f. Disconnect/Test Slot

g. Connect Slot
