Recoil Pull Startup
▲ Before using the generator, read and comply with all Safety Alerts and Icons.
Before starting the generator, make sure the 12V battery is fully charged. The generator requires at least 10.5
cranking volts of battery charge to provide power for startup components and sensors.
To pull-start the generator using the starter grip:
1. Verify that the remote switch is in the OFF position.
2. Insert and turn the ignition key to the ON position. The LCD on the control panel illuminates.
ON
Once the ignition switch is ON, if you do not start the generator within 30 seconds, the LCD dims to conserve
battery power.
3. On the right side of the generator, grasp the starter grip and pull back lightly until resistance is felt, then pull briskly out. Repeat until
the engine starts. Faster pulls generate more spark and enable successful startup.
!
▲ Do not allow the starter grip to snap back. Return it slowly by hand.
▲ Do not pull the starter grip while the generator is running.
▲ Do not let the starter rope rub against the generator body or the rope will wear out prematurely.
The LCD shows output voltage when the generator is ready for use.
4. Connect your appliance to the generator's output receptacle, then turn the appliance on.
Make sure that appliances are in good working condition and that the combined electrical rating of all
connected appliances does not exceed that of the generator (2400W max). If you don't know the watts for your
appliance, multiply the amperage by the output voltage. For example: 20A x 120V = 2400W.
