34
K2 K3 | SERVICE MANUAL
INDEX
Remove the two at cables between the power supply
board and the amplier output board. (Fig. 40)
(Fig. 40)
Flat cable removed
Remove the nuts holding the amplier output board heat sink as portrayed in (Fig. 41)
Nuts unscrewed and removed(Fig. 41)
