56
K2 K3 | SERVICE MANUAL
INDEX
15. Mechanical parts:
GEN 1 GEN 2 GEN 3
Fans through the various evolutions of the K Series.
All are compatible and retroļ¬ttable.
VN000025.R - Actual K Series Fan (Gen 3)
Part Number Description
VI000009 Top Side Cover Screw (short)
VI000024 Heatsink Screw
ME000235 Heatsink Brass Spacer
VI000034 Rear Connector Screw
VI000057 Internal Board Screw
VI000110 Internal Board Pillar
VI000112 Rear Bracket Screw
VI000137 Power Chord Retainer Spacer
VI000138 Side Plate Handle Screw
VI000145 Top Center Cover Screw
VI000170 Central side Plate Screw
ME000363 Lexan Base x KLGT
CB000193 PSU MAIN SWITCH CABLE
ML000011 Power Chord Retainer Spring
