62
K2 K3 | SERVICE MANUAL
K - Series Mechanical parts “Outline vers.”
K_LGT_No_ETH version
Part Number Description
SM00F910.3 Outline_Front_side
SM00P910.3 Outline_T5_Front_Rear_side Rs 485 Vers.
SM00L645.3 K_LGT_Platform Rs 485 Vers.
SM00F910.3 Outline_Front_side
Part Number Qty Description
FI000018 2 Front side lter
IN000010 1 Switch Rocker Single Pole
ME000210 1 K Series LX black plate
ME000213 1 K Series front switch plate
ME000215 1 K Series alluminium front panel
ME000282 1 EMI shield protection
ME000283 1 EMI shield 2 plugs series
ME000318 1 Outline front panel
ME000319 1 Outline RX front side
ME000320 1 Outline LX front side
ME000334 1 K Funcard reader protection
SC000061 1 Trasparent bug
TA000005.00 1 K Series Lexan front protection
VI000021 1 Spacer SPC|M3X12
VI000082 4 Screw SCW|TSPZ_|M4X8
VI000112 4 Screw SCW|TBEI_|M3X6
VI000140 4 Screw SCW|ATCCH|M2.9X6.5
VI000170 5 Screw SCW|TSPH_|M2.5X8
SM00P910.3 Outline_T5_Front_Rear_side Rs 485 Vers.
Part Number Qty Description
ME000321 2 Front side gray plate
ME000284 2 K Series alluminium handle
ME000358 1 Half top rear plate
ME000366.2 1 Outline rear black panel x Rs 485 vers.
ME000375 2 Lateral plate
ME000487 1 MA Outline front plate
ML000016 2 EMI Spring
VI000112 1 Screw SCW|TBEI_|M3X6
SM00P645.3 K_LGT_Front_Rear_side Rs 485 Vers.
Part Number Qty Description
ME000214 2 Front side black plate
ME000284 2 K Series alluminium handle
ME000358 1 Half top rear panel
ME000370.2 1 Rear black panel x Rs 485 vers.
ME000360 2 Lateral inox plate
ML000016 2 EMI Spring
VI000112 1 Screw SCW|TBEI_|M3X6
