12.4 M20D HDSP+ETH
1) DSP preset with high-pass lter and output voltage limiter required.
Specications
General
Number of channels 2
Output power 2-channel mode mono-bridged mode
EIAJ Test Standard, 1 kHz, 1% THD 4 Ω / Ch 8 Ω / Ch 70 V
1)
100 V 8 Ω / Ch pair
1,200 W 600 W 1,200 W -- 2,400 W
Max output voltage / current 116 V
peak
/ 65 A
peak
AC Mains Power
Power supply Universal, regulated switch mode
Operating voltage 115 V / 230 V (factory selection) ± 15%, 50 Hz - 60 Hz
Consumption / current draw @ 230 V @ 115 V
Idle 35 W 0.3 A 35 W 0.6 A
I/8 of max output power @ 4 Ω 371 W 2.54 A 371 W 5 A
I/4 of max output power @ 4 Ω 701 W 4.5 A 701 W 9 A
Thermal
Environmental operating temperature 0° - 45° C / 32° - 113° F
Thermal dissipation Fan, continuously variable speed, temperature controlled, front to rear airow
Idle 126 BTU/h 32 kcal/h
I/8 of max output power @ 4 Ω 529 BTU/h 133 kcal/h
I/4 of max output power @ 4 Ω 935 BTU/h 236 kcal/h
Audio
Gain 32 dB, 30 dB, 28 dB, 26 dB, 24 dB, 22 dB, 20 dB, 18 dB, 14 dB, 4 dB, -∞, user selectable
Frequency response 10 Hz - 30 kHz (1 W @ 8 Ω, ±3 dB)
S/N ratio (amplier section) >107 dBA (20 Hz - 20 kHz, A weighted)
Crosstalk separation >70 dB @ 1 kHz
Input sensitivity @ 8 Ω 1.733 V / 6.98 dBu
Max input level 6 V / 17.7 dBu
Input impedance 10 k
Ω
THD+N / SMPTE IMD � 0.05% @ 1/2 of full power
DIM100 IMD typ. <0.005% (<0.02% @ >0.1 W)
Slew rate 40 V/µs @ 8 Ω, input lter bypassed
Damping factor @ 8 Ω >5000 @ 100 Hz
DSP
A/D converter
CS5381, 2 channels, 24 bit / 48 kHz, 120 dB SNR
D/A converter CS4398, 2 channels, 24 bit / 48 kHz, 120 dB SNR
Frequency response @ -3 dB 7 Hz - 22 kHz
THD < 0.01% (20 Hz - 20 kHz)
Presets Bank of 4 presets, management and upload via Armonía Pro Audio Suite™
Delay for time alignment 10 ms per output
Crossover lters Butterworth, Linkwitz-Riley, Bessel, 6 dB/oct to 48 dB/oct
Output equalizer up to 12 biquad fully parametric per channel: peaking, hi/lo shelving, hi/lo pass, band pass, band stop, all pass; support for custom
FIR lters up to 168 taps per channel (useful for f > 700 Hz)
Input equalizer up to 5 biquad lters (PEQ, shelving, band pass, band stop, all pass)
Limiters
Peak limiter, RMS limiter, frequency dependent RMS limiter
Damping control
< 120 Hz, range ± 2 Ω
System Delay
up to 170 ms for 2 IN/2 OUT or 340 ms for 1 IN/ 2 OUT
Front Panel
Indicators 4 LEDs per channel: 3 x green, 1 x red
2 status LEDs: 1 x green, 1 x yellow
Controls
1 stepped level attenuator pot per channel; mains switch
Maintenance
Dust lter foam behind front panel
Rear Panel
Audio signal input connectors
2 x balanced Neutrik® XLR female
Loudspeaker output connectors 2 x Neutrik® Speakon NL4MD, 2 x Neutrik® XLR male hardwired to the corresponding input
Network data port Ethernet
1 x RJ45 with activity LED with 2 rotary address switches
DSP preset selection
1 x Pushbutton (stepping through bank of 4 presets); 1 x 4 LED preset indicators
Aux voltage
1 x 2-pin Phoenix type MC 1.5/2-ST-3.81
AC mains
IEC C13 16 A connector; AC mains cord with 3-pin plug 15 A for US, IEC Schuko 16 A for every other nation
Controls
1 x link switch, linking analog inputs 1 & 2
Construction
Dimensions W 483 mm / 19”, H 44.5 mm / 1 RU, D 358 mm / 14.1”
Chassis 1 mm (0.04”) steel chassis and steel removable dust cover, 3 mm (0.12”) steel front panel, screw hole protection, steel side
reinforcement & rear support
Weight
7.3 kg / 16 lb
