6
3 Initial Hardware Installation
You will need the two shortest silver screws from the kit found in the accessory box, and the appropriate hex
wrench.
First, lower the build platform by using one of the methods described in the previous section. Holding the extruder
by both sides, take it out of the accessory sleeve and position it on the extruder seat with the fan facing forward.
Align the screw holes and fasten with the two short silver screws.
Next is the installation of the spool holders install one on each side.
The installation of the spool holders is very simple – just insert it into the circular opening and tighten the nut
behind if. Then install the filament guide tube onto the empty spot on the extruder. Place one end of the guide
tube into the hole. The hardware installation is now almost complete.
Next, with the power switch in the OFF position, confirm that the power cord is plugged into the power outlet
next to the power switch.
