POWERVAR Security Plus UPS
28
BYPASS
Input Voltage (VAC) 200 208 220 230 240
Output Voltage (VAC) 200
120
208
240
220 230
120
208
240
Transformer Voltage
Regulation
± 3.0%
Overload
125% for 10 minutes
150% for 500ms
1000% for 1 cycle
Efficiency > 95.0%
BATTERY
Voltage (VDC) 288.0, nominal
327.6, float
Battery 12V, 34W flame retardant
High Rate, Sealed Lead-Acid
Quantity 24
Charge Current (ADC) 2.5
Backup Time (min) > 5.0
Recharge Time 8 hours to 90%
ENVIRONMENT
Temperature (°C) 0 to 40, operating
-20 to 60, transit
Altitude (m) 2,000, operating
12,000, transit
Humidity 5.0% to 90.0%, non condensing
Audible (dBA) 55-60 @ 1m from front of unit
Heat Dissipation (BTU/hr) 4239
AGENCIES
EMC FCC Part 15J Class A
EN 55022 Class A/ CISPR 22
EN 50091-2
IEC 61000-3-2
Safety Agencies UL1778 4
th
Ed.
cUL to CSA22.2 No.107.1
IEC62040, w/CB report and certificate
IEC61000-4-2, Electrostatic Discharge
IEC61000-4-3, Radiated Electromagnetic Field Immunity
IEC61000-4-4, Electrical Fast Transient/ Burst Immunity
IEC61000-4-5, Surge Immunity
IEC61000-4-6, Immunity to Conducted Radio Frequency Disturbances
IEC61000-4-8, Power Frequency Magnetic Field Immunity
IEC61000-4-11, Voltage Dips, Short Interruptions, and Voltage Variations
RoHS All units are RoHS compliant
OTHER
Communication RS-232
USB
DB-9 Dry Contacts
Internal SNMP Adapter (optional)
Unit Weight 719.0lbs/ 326.1kg (12kVA) 739.0lbs/335.2kg (15kVA)
Shipping Weight 807.0lbs. / 366.0 kg (12kVA) 827.0lbs/ 375.1kg (15kVA)
Plug & Receptacle* *Hardwire unit is standard. Plug & receptacle is optional. Contact factory for part numbers.
NOISE REJECTION-ISOLATION: With unit under power and an ANSI/IEEE C62.41Cat. A pulse applied either normal or common mode at the input, the noise output
voltage will be less than 10V normal mode and less than 0.5V common mode in all four quadrants (CM-NM, NM-NM, CM-CM, NM-CM).
SURGE VOLTAGE WITHSTAND CAPABILITY: Tested under power to ANSI/IEEE C62.41 Cat. A & B (formerly IEEE587-1980). Cat. A - 6000V @ 200
amps, 0.5 usec risetime, 100 kHZ decay, Cat. B - 6000V @ 500 amps, 0.5 usec risetime, 100 kHZ decay.

