Getting Started
1.1 Required Tools and Equipment
R e f e r t o Tab l e s 1 --- 1 , 1 --- 2 , 1 --- 3 f o r t h e t o o l s a n d e q u i p m e n t r e q u i r e d t o r e mo v e o r
install transformers T1 and T3.
Ta b l e 1 --- 1 . To o l s
Tool Specifications Comments
Common Ha nd Tools N/A
Metric Open End Wrench Set N/A Use 13mm wrench for
transformer lug bolts and nuts.
Metric Socket set N/A Use 13mm socket for
transformer lug bolts and nuts.
Torq u e W r en c h 0to25Nmminimum Usedforalltransformerlug
bolts
Allen Wrench 5/32 inch Used for K6 terminals
Table 1---2. Heavy Equipment
Equipment Specifications
Fork Lift Truck 4000 pound lifting capacity minimum
Table 1---3. Test Equipment
Equipment Specifications
Dielectric Voltage
Withstand Tester
SCalibrated AC or DC potential output
SApplied potential indicator
SAudible or visual indicator of electrical breakdown
S
If the output t ransformer is less then 500 VA then the voltage meter
must be connected across its output. If the output transformer is
greater then 500 VA then the voltage may be measured on either the
primary or a tertiary winding.
Tes t Jum pers Various Lengths (3 feet to 10 feet)
Timing Device Watch, clock or stopwatch
