Powerware 9315 - Page 30

3-- 8
Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
H1
H2
H3
TRANSFORMER TERMINALS
X1
X2
X3
GROUND WIRE
TRANSFORMER TERMINALS
Y01 Y02
Y03
Y1 Y2 Y3
Figure 3 ---6. Transformer T3 Wiring
