3-- 11
Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
7. Move blower assembly wiring harness into p osition behind blowers.
8. Reconnect blower connectors B1P1 through B4P1 to connectors B1J1 through
B4P1 on wiring harness.
9. Install vertical center channel, with transformer baffle attached, to cabinet while
carefully engaging transformer baffle over transformer (see figure 3---2).
10. Secure vertical center channel to cabinet with four top and two bottom screws.
11. Secure left side of transformer baffle to cabinet with one screw
( s e e f i gu r e 3 --- 2 ) .
12. Install four rear panels onto cabinet as follows (see figure 3---1):
a. Install panel 4 over four screws at bottom of cabinet base. Secure with
six screws on sides of panel and four at the bottom of panel.
b. Install panel 3 over four screws at bottom of cabinet base. Secure with
six screws on sides of panel and four at the bottom of panel.
c. Install panel 2 above panel 4, inserting screws in bottom of panel into
slots at the top of panel 4. Secure with ten screws on top and sides
and four screws at bottom of panel.
d. Install panel 1 above panel 3, inserting screws in bottom of panel into
slots at the top of panel 3. Secure with ten screws on top and sides
and four screws at bottom of panel.
13. Install doors and top door hinges.
14. Close cabinet doors.
