Powerware 9315 - Page 45

4-- 11
Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
Table 4---2. T1 Input and Output Wi re Connections
Wire
Number
Number
of Wires
To
Tightening
Torque
N-M (lb-ft)
Notes
145 2 T1-H1 23(18.4)
146 2 T1-H2 23(18.4)
147 2 T1-H3 23(18.4)
148 2 T1-H1 23(18.4)
149 2 T1-H2 23(18.4)
150 2 T1-H3 23(18.4)
151 2 T1-H1 23(18.4)
152 2 T1-H2 23(18.4)
153 2 T1-H3 23(18.4)
157 3 T1-X01 23(18.4)
158 3 T1-X02 23(18.4)
159 3 T1-X03 23(18.4)
160 3 T1-X1 23(18.4) Used when CB3 is not required
161 3 T1-X2 23(18.4) Used when CB3 is not required
162 3 T1-X3 23(18.4) Used when CB3 is not required
260 3 T1-X1 23(18.4) Used when CB3 is required
261 3 T1-X2 23(18.4) Used when CB3 is required
262 3 T1-X3 23(18.4) Used when CB3 is required
163 1 T1-X1 23(18.4) Used with 480 Volt units only
164 1 T1-X2 23(18.4) Used with 480 Volt units only
165 1 T1-X3 23(18.4) Used with 480 Volt units only
163A 1 T1-X11 23(18.4) Used with 600 Volt units only
164A 1 T1-X21 23(18.4) Used with 600 Volt units only
165A 1 T1-X31 23(18.4) Used with 600 Volt units only
