5-- 3
Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
5. Remove screw securing left side of transformer baffle to cabinet
( s e e f i gu r e 5 --- 3 ) .
6. Remove four top and two bottom screws securing vertical center channel to
cabinet (see figure 5---3).
7. Carefully disengage transformer baffle from transformer and remove vertical
center channel with baffle attached from cabinet.
8. Remove three screws securing vertical center channel bracket to cabinet, and
removebracket(seefigure5---4).
9. Disconnect blower connectors B1P1 through B4P1 and move wiring harness
to left side of cabinet.
10. Remove five front screws securing blower assem bly B1---B4 to cabinet base
( s e e f i gu r e 5 --- 5 ) .
11. Loosen three screws securing the back of blower assembly B1---B4 to cabinet
b a s e ( s e e f i g u r e 5 --- 5 ) .
WARNING:
Blower assembly B1--B4 are heavy and may require two persons to remove.
12. Slide blower assembly forward to disengage screws and remove assembly
( s e e f i gu r e 5 --- 5 ) .
13. Remove Input Filter A2 panel from cabinet as follows (see figure 5---6):
a. Disconnect wires from K6 terminals 2T1, 4T2 and 6T3.
b. Disconnect connector A2P1 from A2J1.
c. Loosen three bottom screws on Input Filter A2 panel.
d. Remove three top screws from Input Filter A2 panel and remove panel.
14. Remove four screws from lower deadfront panel and remove panel.
15. Remove CPT4 panel from cabinet as follows (see figure 5---6):
a. Disconnect connector P4 from J4.
b. Loosen three bottom screws on CPT4 panel.
c. Remove three top screws from CPT4 panel and remove panel.
