Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
DEADFRONT
PANEL
BOTTOM
SCREWS
INPUT
FILTER
PANEL A2
K6
CPT4
PANEL
A2P1/A2J1P4/J4
Figure 5 ---6. Input/Rectifier Cabinet Front Interior View Blowers Removed
