Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
7. Move blower assembly wiring harness into p osition behind blowers.
8. Reconnect blower connectors B1P1 through B4P1 to connectors B1J1 through
B4P1 on wiring harness.
9. Install vertical center channel, with transformer baffle attached, to cabinet while
carefully engaging transformer baffle over transformer (see figure 5---3).
10. Secure vertical center channel to cabinet with four top and two bottom screws.
11. Secure left side of transformer baffle to cabinet with one screw
( s e e f i gu r e 5 --- 3 ) .
12. Proceed to Chapter 6 Dielectric Testing in this manual. Do not reinstall front
doorsorrearpanels.
