Installation
36
Powerware
®
PrestigeSeriesInstallationand Operator’s ManualforIBM Applications (6000 VA)Uncontrolled Copy
PPU Battery Cabinets
Battery
Circuit
Breaker
Battery Connector
Breaker Tie
Battery Connector Guard
Voltage
Selector
Switch
Serial Port
Input PlugInput Breaker
Output
Receptacle
REPO
Receptacle
Battery
Connector
Figure 9. UPS with Battery Cabinets (Rear View)
