Chapter 5 Function parameter
102
Chapter 5
Hundreds digit
VDO3(0～1，same as above)
Thousands
digit
VDO4(0～1，same as above)
Tens of
thousands digit
VDO5(0～1，same as above)
E3.17
VDO1 delay time
0.0s～3600.0s
0.0s
☆
E3.18
VDO2 delay time
0.0s～3600.0s
0.0s
☆
E3.19
VDO3 delay time
0.0s～3600.0s
0.0s
☆
E3.20
VDO4 delay time
0.0s～3600.0s
0.0s
☆
E3.21
VDO5 delay time
0.0s～3600.0s
0.0s
☆
VDO is similar to the DO output function, can be used to communicate and coordinate
with VDIx implement some simple logic control
when VDOx output function selection of 0, VDO1 ~ VDO5 output state determined by
DI1 ~ DI5 input status on the control panel, as VDOx with VDIx one-to-one correspondence
When selecting VDOx output function is not zero, the function of VDOx setting is the
same with F2 group DO output parameters, please refer to the F2 group of related parameters
The output valid state of the VDOx can be set by E3.16, select is logic or logic
5-2-19.E8 group Wire cutting machine group
Code
Parameter name
Setting range
Factory
setting
Change
limits
E8.00
Wire cutting machine
running mode
forbid
0
0
★
enable
1
When set the wire cutting machine mode , if use terminal control (F0.11 = 1 or 4), you
need to set up for a three line mode.
Note: under the E8.00=1 enable mode, the default values for some parameters are:
Code
Default
value
Code
Default
value
Code
Default
value
Code
Default
value
F0.03
6
F0.11
1
F0.13
0.8
F0.14
0.6
F1.02
12
F1.03
13
F1.04
14
F2.02
4
F2.11
0.6
F3.10
100
F3.11
0.2
E1.00
100
E1.01
40
E1.02
30
E1.03
20
E1.04
20
E8.01
Reciprocating motion ahead of time
0.0~600.0s
4.0s
☆
When cutting machine running mode, when the inverter DI terminal function set to 53
reciprocating motion input, and terminal is valid, this parameter is defined as the motor forward
time in reciprocating mode.
E8.02
Reciprocating motion back time
0.0~600.0s
2.0s
☆
When cutting machine running mode, when the inverter DI terminal function set to 53
reciprocating motion input, and terminal is valid, this parameter is defined as the motor reverse
time in reciprocating mode.
E8.03
0Hz Frequency to check out
invalid
0
0
★
valid
1
Set E8.04 high-frequency output frequency to check out the width, when choosing 0 Hz
frequency reaches detection as invalid, the inverter in the 0 Hz run DO not output terminal
E8.04
The high frequency output
0~100%
99%
☆
This parameter based on a set frequency, when F2.02 or F2.04 choose 42 high frequency
output, the output frequency is greater than or equal to the parameters set suction, the relay or
SPA will action after E8.06 set time
E8.05
High frequency output frequency is disconnected
0~100%
99%
☆
