Powtran PI160 Series - Keyboard Dimension

Chapter 7 Outline dimension
116
Chapter 7
Base
No.
Power supply
level
Type
Power
(kW)
Dimensions(mm)
Installation
Size(
mm
)
Approxi
mate
weight
(kg)
L
W
H
h
a
b
d
1M2
Single phase 220V
G
0.4~0.75
142
85
122.8
112
130
73
φ5.3
0.8
Three phase 220V
G
0.4~0.75
1M3
Single phase 220V
G
1.5~2.2
151.6
100.6
127.5
116.6
139.7
88.7
φ5.3
1
Three phase 220V
G
1.5~2.2
Three phase 380V
G
0.4~3.7
7-1-3. Keyboard dimension
JP160 Dimension:
