Powtran PI160 Series User Manual

Chapter 5 Function parameter
23
Chapter 5
performance
FC
Extend parameters group
Special application parameters setting
E0
Wobbulate, fixed-length and
counting
To set Wobbulate, fixed-length and counting function
parameters
E1
Multi-stage command, simple PLC
Multi-speed setting, PLC operation
E2
PID function group
To set Built-in PID parameters
E3
Virtual DI, Virtual DO
Virtual I/O parameter setting
E8
Special for Cutting machines
Cutting machines parameters setting
b0
Motor parameters
To set motor parameter
y0
Function code management
To set password, parameter initialization and
parameter group display
y1
Fault query
Fault message query
5-1-1.d0 Group - Monitoring function
No.
Code
Parameter name
Setting range
Factory
setting
1
d0.00
Running frequency
Actual output frequency
0.01Hz
2
d0.01
Set frequency
Actual set frequency
0.01Hz
3
d0.02
DC bus voltage
Detected value for DC bus voltage
0.1V
4
d0.03
Inverter output voltage
Actual output voltage
V
5
d0.04
Inverter output current
Effective value for Actual motor current
0.01A
6
d0.05
Motor output power
Calculated value for motor output power
0.1kW
7
d0.06
Motor output torque
Motor output torque percentage
0.1%
8
d0.07
DI input status
DI input status
-
9
d0.08
DO output status
DO output status
-
10
d0.09
AI1 voltage (V)
AI1 input voltage value
0.01V
11
d0.11
Panel potentiometer voltage
Panel potentiometer voltage
0.01V
12
d0.12
Count value
Actual pulse count value in counting
function
-
13
d0.13
Length value
Actual length in fixed length function
-
14
d0.14
Actual operating speed
Motor actual running speed
-
15
d0.15
PID setting
Reference value percentage when PID
runs
%
16
d0.16
PID feedback
Feedback value percentage when PID runs
%
17
d0.17
PLC stage
Stage display when PLC runs
-
