Powtran PI160 Series User Manual

7
第
十
章
Chapter 2
Chapter 2 Standard specifications
2-1.Technical specifications
Inverter
model
Rated output
power(kW)
Rated input
current(A)
Rated output
current(A)
Adaptive
motor(kW)
Single phase supply voltage 220V + 10%
PI160-0R4G1(Z)
0.4
5.4
2.5
0.4
PI160-0R7G1(Z)
0.75
8.2
4.0
0.75
PI160-1R5G1(Z)
1.5
14.0
7.0
1.5
PI160-2R2G1(Z)
2.2
23
10.0
2.2
Three phase supply voltage 220V + 10%
PI160-0R4G2(Z)
0.4
4.1
2.5
0.4
PI160-0R7G2(Z)
0.75
5.3
4.0
0.75
PI160-1R5G2(Z)
1.5
8.0
7.0
1.5
PI160-2R2G2(Z)
2.2
11.8
10.0
2.2
Three phase supply voltage 380V±10%
PI160-0R4G3Z
0.4
2.0
1.2
0.4
PI160-0R7G3Z
0.75
4.3
2.5
0.75
PI160-1R5G3Z
1.5
5.0
3.8
1.5
PI160-2R2G3Z
2.2
5.8
5.1
2.2
PI160-3R7G3Z
3.7
10
8.5
3.7
Note:220V series brake unit is optional accessory; 380V series brake unit is standard
accessory.
2-2.Main circuit terminal screw specifications
Inverter model
Main circuit terminal screw
specifications
Tightening torque
(Nm)
PI160-0R4G1(Z)
M3
0.5～0.7
PI160-0R7G1(Z)
PI160-1R5G1(Z)
PI160-2R2G1(Z)
PI160-0R4G2(Z)
PI160-0R7G2(Z)
PI160-1R5G2(Z)
PI160-2R2G2(Z)
PI160-0R4G3Z
