Powtran PI160 Series User Manual

Chapter 4 Installation and commissioning
21
Chapter 4
4-8.Commissioning
Commissioning
Select control way
（ Set F0.00）
F0.00=?
V/F
Control
2
Select commend source
（ Set F0.11）
Select frequency source
（ Set F0.03、F0.04、F0.07,etc）
（Set F0.13、F0.14）
Start the motor running, observation, if
there are any abnormal, please refer to
the troubleshooting
End
Select motor starter method
（ Set F3.00）
NO
YES
Achieve the required control
effect？
0
Vector control W/O PG
Select motor stop method
（Set F3.07）
Correct set motor parameter
Select deceleration time
Motor parameter self learning
（ Set b0.27）
Set b0.00-b0.05)
（ Set F0.13、F0.14）
Select deceleration time
Figure 4-4.Commissioning
● Firstly confirm that AC input power supply voltage shall be within inverter rated input
voltage range before connecting power supply to the inverter.
● Connect power supply to the R, S and T terminals of the inverter.
● Select the appropriate operation control method.
