Chapter 1 Inspection and safety precautions
POWTRAN frequency inverters have been tested and inspected before leaving factory. After
purchasing, please check if its package is damaged due to careless transportation, and if the
specifications and model of the product are consistent with your order requirements. For any
problem, please contact your local authorized POWTRAN dealer or directly contact this company.
1-1.Inspection after unpacking
※ Check if that packing container contains this unit, one manual and one warranty card.
※ Check the nameplate on the side of the frequency inverter to ensure that the product you
have received is the right one you ordered.
1-1-1.Instructions on nameplate
Figure 1-1:Nameplate description
1-1-2.Model designation
Powtran Inverter
Rated output capacity
Example: 1R5: 1.5kW
Function code
G: Standard load
Series Code
160:PI160 series
Input Voltage Level
1: Single-phase 220V
2: Three-phase 220V
3: Three-phase 380V
Output configuration
0:Standard configuration without
braking unit (omitted)
Z:With brake unit(option)
Figure 1-2:Model description
