PPI FLOREX User Manual

The Serial Configuration Parameters are grouped on Serial Config. Page and allows the user to configure the FLOREX to
communicate with master devices like PC or Digital Recorders. The Digital (Serial) communications facilitate the FLOREX to
communicate with a Master Device like Digital Recorder or PC via MODBUS (RTU) protocol, if hardware module (RS 485 / RS
232) is fitted. The parameters required for setting MODBUS communication are described as under:
SERIAL CONFIGURATION PARAMETERS
Settings
(Default Value)
4800
9600
19200
38400
57600
(Default : 9600 bps)
None
Even
Odd
(Default : Even)
1 to 127
(Default : 1)
Parameter Description
BAUD RATE
This parameter defines the communication speed expressed in
“Bits per Second” (bps). The settable values are 4800, 9600,
19200, 38400 and 57600. The Baud Rate must be set to match the
Baud Rate set for the Master Device.
This parameter is a part of communication protocol and helps
detecting communication errors. The settable values are ‘None’,
‘Even’, and ‘Odd’. The parity type must be set to match the parity
type set for the Master Device.
PARITY
This parameter assigns an identification number for the
communication with Master Device. The Master Device uses this
ID to uniquely address the instrument for data transactions. The
settable values are from 1 to 127.
SERIAL ID
The Read/Write parameters can be accessed for both reading and
writing. The Read/Write parameters can only be accessed for
reading. That is the parameter values cannot be altered through
serial communication.
SERIAL WRITE PERMISSION
No
Yes
(Default : No)
User Manual
FLOREX
23
Table 9.1
Section 9
