PPI FLOREX User Manual

The Retransmission (Recorder) Output Parameters are grouped on Retransmission Page and allow the user to configure the
FLOREX for Retransmission (Recorder) Output.
The Table 6.1 below lists the parameters followed by the definitions for each parameter.
RETRANSMISSION PARAMETERS
User Manual
FLOREX
18
Parameter Description
Settings
(Default Value)
0 to 20 mA
4 to 20 mA
0 to 5 Volts
0 to 10 Volts
(Default : 0 to 20 mA)
-19999 to 30000
(Default : 0)
This parameter is available and applicable only if the FLOREX is
ordered with ‘Retransmission’ (Recorder) output option and sets
the range for the recorder signal output as 0-20 mA, 4-20 mA, 0-5
V or 0- 10 V. The FLOREX outputs a linear 0-20 mA, 4-20 mA, 0-5
V or 0-10 V signal, through the optional DC Linear output,
proportional to the Flow Rate within ‘Low Range’ and ‘High Range’
values.
RETRANSMISSION OUTPUT TYPE
( Available for DC Linear Inputs)
Sets process value corresponding to minimum DC Linear signal
input (e.g., 0V, 0mA, 4mA, etc.)
LOW RANGE
( Available for DC Linear Inputs)
Sets process value corresponding to maximum DC Linear signal
input (e.g., 5V, 10V, 20mA, etc.)
HIGH RANGE
-19999 to 30000
(Default : 1000)
Table 6.1
