PRECISION DIGITAL PD603 - MOUNTING DIMENSIONS

Sabre P ● Model PD603 Process Meter Instruction Manual
MOUNTING DIMENSIONS
1.76"
(45mm)
0.59"
(15mm)
3.2"
(81mm)
2.45"
(62mm)
3.6"
(91mm)
Figure 7. Meter Dimensions - Side View
3.61"
(92mm)
2.50"
(64mm)
4.68"
(119mm)
Figure 8. Case Dimensions - Top View
29
