Precor EFX 534I - Hardware Kit

EFX524i Elliptical Fitness Crosstrainer Assembly Guide 2
Hardware Kit (not to scale)
1 — ³⁄₁₆-inch hex key
1 — ⁵⁄₃₂-inch hex key
Fasteners Quantity
(A) Phillips-head screw (½-inch)
4
(B) Buttonhead screw (¾-inch)
4
(C) Hex head screw (1-inch)
22
(D) Washer (³⁄₈-inch)
22
1 — Height adjuster with hex nut
1 — End cap
