2Operation Verification
This section provides a method of verifying the TRM10/GEN06 Treadmill Base operation.
Check the treadmill operation at the end of a maintenance procedure and when it is necessary
to ensure that the treadmill is operating properly.
"Operation Verification Procedure" below
"Operation Verification Checklist" on the facing page
Operation Verification Procedure
Perform these tests to verify operation of the unit.
1. Plug the power cord into the wall outlet and switch the power switch to the "ON" pos-
ition.
2. Press and hold the RESET key for a minimum of 6 seconds, if errors are logged, the
error log will be displayed. Make note of all logged error codes and odometer reading.
The odometer reading can help you determine the age and relevance of the error.
Note that on P80 consoles, go to the error event log to view logged errors, see "Access-
ing the Service Software" on page10.
3. Clear the error log; select a logged error and then hold down the QUICK START key
until the error is deleted.
4. Enter the Hardware Validation Test by entering access code 5,1,7,6,5,7,6,1:
a. Press either the STOP, PAUSE or RESET buttons and then enter
5,1,7,6,5,7,6,1
Note: For P80 consoles, refer to "Accessing the Service Software" on page10.
5. Select and run the Display Test, the Keypad Test, and the Heart Rate Test, Verify that
each test is successfully completed with the following results:
l LEDs light
l Keys all function
l Heart rate is acquired and displayed
6. Enter the Machine Tests submenu and run the Belt Speed Test and the Incline Test.
Verify following results:
l Running belt operates from minimum to maximum speed.
l Incline moves up and down and the A/D value is approximately 6000+/-500 at 0%
incline.
7. Press the RESET key to exit diagnostics. On P80 consoles, press Back to exit dia-
gnostic and return to the Home page.
8. Operate the unit in the Manual program. Adjust the speed of the running belt to 2–3
mph. Operate the treadmill for at least 5 minutes while walking on the unit.
