Auto Stop Sensor Replacement
About
This procedure provides instruction to remove and replace the Auto Stop Sensor.
Procedure
Review entire procedure before starting.
CAUTION: Do not place the Auto Stop Magnet on or near a steel structure. If the
magnet assembly comes in contact with a steel structure and then pulled away from
the steel structure, the magnet can become dislodged from the magnet assembly
housing. Contact PRECOR customer service for repair or replacement.
1. Set the treadmill circuit breaker to OFF and unplug the treadmill’s power cord.
2. Remove the front hood and right side step cover.
3. Unplug the Auto Stop Cable from the Auto Stop assembly.
4. The Auto Stop Sensor assembly has round alignment tabs that match the holes of the
treadmill frame support. With one hand grasp the side of the Auto Stop Sensor
assembly that is closest to the outside of the treadmill and apply pressure toward the run-
ning deck. With your other hand push on each alignment tab from the inside of the frame
mounting holes. The Auto Stop Assembly should disengage from the frame.
5. Position the replacement Auto Stop assembly with the cable connector facing to the
right side of the treadmill. Slide the Auto Stop assembly over the treadmill frame support
and push down until the round tabs align with the holes in the support. The round tabs
will snap into the treadmill frame mounting holes securing the Auto Stop assembly in
place.
6. Check the alignment of the magnet and the Auto Stop assembly. The magnet and the
Auto Stop assembly each have an alignment mark on the top of their housings. The
magnet mark and the Auto Stop mark should align and the gap should be approximately
3/16 of an inch between the housings. A 3/16 hex key can be used as a feeler gauge to
set the correct gap. If the gap or alignment are off adjust the running deck until the mag-
net and auto housing are properly aligned, see "Auto Stop Magnet Replacement" on
page30.
