DIAGNOSTIC
TEST
TEST DESCRIPTION
Press the back button to exit this test.
Belt Test
Tests the belt speed in 0.1 mph increments showing the required Input
Voltage, Input Current to the treadmill, the Output Voltage, and Drive
Motor current at each speed.
Auto Stop Test
Tests the Auto Stop function showing the averaged foot plants and exerciser
"is detected"/ "is not detected" function. Foot plant averaging delay resets
with each speed change.
Incline Test
Tests the incline & Decline function. Allows you to verify the A/D number at
any incline level and the number of Glitches (communication time between
the LPCA and UPCA).
Stop Key Test
Tests the Stop Key function for P10 and P30 console s.
Test procedure prompts to press the Stop Button, then disconnect and recon-
nect the Lanyard E-Stop, and then press Stop to reset and exit the test.
P80 Series Consoles:
On P80 consoles, Diagnostic Tests are located on the Diagnostic tests and hardware cal-
ibration page:
l Access code 51765761
l select System Settings
l Select System Tests
l Opens Diagnostic tests and hardware calibration page, select test from menu.
DIAGNOSTIC
TEST
TEST DESCRIPTION
Auto Stop Test Tests the Auto Stop function showing the averaged foot plants and exerciser
"is detected"/ "is not detected" function. Foot plant averaging delay resets
with each speed change.
Belt Speed Test Tests the belt speed by stepping the speed in 0.1 mph increments and show-
ing the required drive motor current.
Incline Test Tests the incline & Decline function. Allows you to verify the A/D number at
any incline level and the number of Glitches (communication time between
the LPCA and UPCA).
USB Test Shows detected USB devices.
Touchscreen Test Use finger to draw line across touch-screen. Select Finish to exit.
Touchscreen Cal-
ibration
Touch the cross points on the touch screed to proceed through the calibration
procedure.
Backlight Test Tests the console LEDs. Successively press the OK key to verify each group
of LEDs and verify that all LED's illuminate. Press Back to exit the test.
RGB Test Test the touch-screen RGB colors. Touch screen to advance through the red,
green, blue, and white colors.
Speaker Test Tests speakers.
(Undefined variable: TRM700-16Base.ServiceManualTitle)
14
3 Standard Service Software
Hardware Validation - Diagnostic Tests (51765761)
