16. Connect the frame ground wire to the treadmill frame, Make sure to route the cable
using the frame cable clips to secure the able in position. Securely tighten the mounting
screw to ensure very good electrical connectivity.
17. Connect the Lift Motor connector to the INCLINE connector on the power control mod-
ule. Make sure to route and use the frame cable clips to safely secure the cable away
from the jack screw.
18. Connect the Lift Motor connector to the LIFT connector on the motor control module.
Make sure to route and use the frame cable clips to safely secure the cable away from
the jack screw.
19. Return the treadmill to the upright position.
20. Level the Treadmill.
21. Install the hood.
22. Plug in the power cord and Switch the input power to ON.
23. Verify the treadmill incline operation through the full range of motion. Do the "Hardware
Validation - Diagnostic Tests (51765761)" on page13 - INCLINE TEST diagnostic test.
24. Verify treadmill operation (see "Operation Verification" on page8) and return to service.
See Also
"Replacement Procedures" on page29
"Lift Motor Calibration" on page24
(Undefined variable: TRM700-16Base.ServiceManualTitle)
50
5 Replacement Procedures
Incline Lift Motor Replacement
