S3.25 Leg Press Option Assembly Instructions
page 17
1 2 3 4 5 6
B
Rotate the
Cam Washer
Top Cap
Weight
Weight Pin
A
Top Cap
Weight
C
Top Weight
Weight then further adjustments are needed.
Continue with steps 2 and 3.
2. Rotate the Cam Washer
If the Top Cap Weight does not rest on the Top Weight,
you must make further adjustments.
A. Remove excess tension from the Cable by placing
the Weight Pin into the Selector Stem just under the
Top Cap Weight.
B. To tighten or loosen the Cable tension, rotate the
Cam Washer.
C. Look to see that Top Cap Weight rests squarely on
the Weight Stack. If it does, no more adjustments are
needed and the Leg Press Option is ready to use. If
the Top Cap Weight does not rest on the Top
Weight, then further adjustments are needed.
Continue with step 3.
Step 2. Rotate the Cam Washer

Precor S3.25 Specifications

Weight and Dimensions

length	60 inches (152 cm)
height	33 inches (84 cm)
width	30 inches (76 cm)
shipping weight	125 lb (57 kg)
