Precor S3.25 User Manual

S3.25 Leg Press Option Assembly Instructions
page 3
Table of Contents
Table of Contents
Important Safety Instructions ............................................................... 2
Personal Safety During Assembly .................................................................................. 2
Obtaining Service .......................................................................................................... 2
Before You Begin ................................................................................... 4
Unpacking the Equipment .............................................................................................. 4
Preparations........................................................................................... 5
Required Tools ............................................................................................................... 5
Installation Requirements .............................................................................................. 5
Assembly Tips ............................................................................................................... 5
Assembly Instructions .......................................................................... 6
1. Remove the Shroud ................................................................................................... 7
2. Attach the Cross Brace to the S3.25 .......................................................................... 8
3. Assemble the Frame .................................................................................................. 9
4. Assemble the Seat Pads ............................................................................................ 11
5. Route the Cable ......................................................................................................... 12
6. Assemble the Cable and Pulleys ................................................................................ 13
7. Replace the Shroud ................................................................................................... 15
Adjustments ........................................................................................... 16
1. Stretch the Cable ....................................................................................................... 16
2. Rotate the Cam Washer ............................................................................................. 17
3. Adjust the Rubber Bumper on the Leg Press Option .................................................. 18
Warranty Card ....................................................................... Back cover
Specifications ....................................................................... Back cover
1
2
3
4

Precor S3.25 Specifications

Weight and Dimensions

length	60 inches (152 cm)
height	33 inches (84 cm)
width	30 inches (76 cm)
shipping weight	125 lb (57 kg)
