Precor S3.25 User Manual

S3.25 Leg Press Option Assembly Instructions
page 7
1 2 3 4 5 6
1. Remove the Shroud
Important: For ease of assembly, the fasteners and
hardware for each step are labeled and packaged in
separate bags.
Note: If you are assembling the Leg Press Option along
with your S3.25, go directly to Step 2.
Before you can attach the Leg Press Option to the unit, you
must remove the Shroud.
A. Remove the Shroud by loosening and removing
six 2¾-inch bolts
six washers
six locknuts
B. Pull the Shroud away from the S3.25 and lay it and
its fasteners on the floor in a secure place.
Note: The top of the Shroud has a notch in it to
help you clear the Top Beam fastener.
A
6 - 2¾" bolts
6 - washers
6 - locknuts
B
Remove Shroud
Notch in Shroud fits
around Top Beam
fastener
Top Beam
Step 1. Remove the Shroud

Precor S3.25 Specifications

Weight and Dimensions

length	60 inches (152 cm)
height	33 inches (84 cm)
width	30 inches (76 cm)
shipping weight	125 lb (57 kg)
