S3.25 Leg Press Option Assembly Instructions
page 15
1 2 3 4 5 6
7. Replace the Shroud
A. Pick up the Shroud and fasteners from the location
where you left them in Step 4B.
B. Replace the Shroud by realigning the mounting
holes and inserting
six 2¾-inch bolts
six washers
six locknuts
Wrench tighten.
Step 7. Replace the Shroud
B
6 - 2¾" bolts
6 - washers
6 - locknuts
A
Replace Shroud
Notch in Shroud fits
around Top Beam
fastener
Top Beam

Precor S3.25 Specifications

Weight and Dimensions

length	60 inches (152 cm)
height	33 inches (84 cm)
width	30 inches (76 cm)
shipping weight	125 lb (57 kg)
