© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 73
Removing and replacing the Deck Trim Landing Strips.
1. Set the treadmill circuit breaker in the off position and unplug the treadmill’s line cord from the
AC outlet.
2. Remove the hood.
3. Remove the screw, washer and spacer from the front of the Deck Trim Landing Strip.
4. At the rear of the tread, grasp the inside of the trim, and sharply pull up to unsnap the trim from
the rear cover.
5. Grasp the landing and pull back sharply, about ¾ inches, to detach the trim from its mounts.
6. Install the new landing in the reverse order. It may help to lock the tab in the back by flexing the
landing, allowing room for the lock to slip past the edge of the rear cover.
7. Install the screw, washer and spacer; torque the screw to 30 in-lbs. The spacer is important to
prevent the screw compromising the plastic in the landing.
8. Replace the hood.
9. Check treadmill operation per, Checking Treadmill Operation.
