Primus XCONTROL PLUS - Page 48

48 PROGRAMOVACÍ MANUÁL 540876_A_PUB_DATE_1_FEB_2012.DOC
 THE EXTRACT SEQUENCE
Menu Item Default Info Limits
Drain Valve 1 Only available on washing machines with both : a
normal Open and normal Closed Drain valve.
1 - 2
RPM - The suggested RPM depends on the machine Type. See table 3.5.B
Time 4.5 Min The Extract Sequence Time.
(for 0 Minutes the Extract sequence will be skipped)
(programmable in steps of 0,5 Minutes)
0 - 15,0 Min
Exit Return to Edit Program Menu.
 THE NO DRAIN SEQUENCE
 The Drain/Extraction part of the programmed step is skipped.
Attention!
For some specific functions „No Drain“ must be programmed.
Example:
If you want to program a Cool-down Sequence, then „No Drain“ must be programmed between the Hot Wash
and the Cool-down Sequence.
Menu Item Default Info Limits
Exit Return to Edit Program Menu.
 THE STATIC DRAIN SEQUENCE
The drum is at standstill while the water is drained.
Menu Item Default Info Limits
Drain Valve 1 Only available on washing machines with both :
a normal Open and normal Closed Drain valve.
1 - 2
RPM - The suggested RPM depends on the machine Type. See table 3.5.B
Time 0.5 Min The Static Drain Sequence Time.
(for 0 Minutes the Static Drain sequence will be skipped)
(programmable in steps of 0,5 Minutes)
0 - 15,0 Min
Exit Return to Edit Program Menu.
!
