TROUBLESHOOTING
TEST SEQUENCE
Display test and door lock test
Sensor test
Motor test
Water fill, heating and drain test
BASIC Diagnostic Wash program
Test Info Explanation
1
Black display followed
by a Text display.
Door lock test (locks and unlocks 5 x the door)
Display test
***
None Sensor test (all wash machine sensors are
tested)
3
Motor Reverse Wash speed (inverse direction high spin)
4
Motor Stop
Standstill motor
5
Motor Forward Wash speed (same direction high spin)
6
Motor Distribute Distribution speed (same direction high spin)
7
Motor Low spin Low spin speed (same direction high spin)
8
Motor High spin High spin speed
(the drum is turning away from the soap box)
9
Motor Stop Free run or controlled deceleration
20
Inlet I1 The machine takes water by inlet 1
21
Drain 1 The water is drained by drain valve 1
22
Inlet I2 The machine takes water by inlet 2 until the
safety level for heating is reached
Heating activated (only if Wait temp = on)
23
Drain 1 (2)* The water is drained by drain valve 1
24
Inlet I3 The machine takes water by inlet 3
25
Drain 1 The water is drained by drain valve 1
26
Inlet I4 The machine takes water by inlet 4
27
Drain 1 The water is drained by drain valve 1
28
Inlet I5 The machine takes water by inlet 5
29
Drain 1 The water is drained by drain valve 1
30
Inlet I6 The machine takes water by inlet 6
31
Drain 1 The water is drained by drain valve 1
32 Inlet I7 The machine takes water by inlet 7
33 Drain 1 The water is drained by drain valve 1
34 Inlet I8 The machine takes water by inlet 8
35 Drain 1 The water is drained by drain valve 1
50 Tumble
The tumble sequence
Unload
End of the Diagnostic Cycle
Note : * The second drain valve will be opened if a second drain valve has been selected in the
Configuration menu.
*** No number 2 is displayed at the sensor test as this takes only a fraction of a second.
Remark!
If ++ ++ is displayed at the motor test sequence, then you can Advance (Press START) the test Sequence.
