540876_A_PUB_DATE_1_FEB_2012.DOC PROGRAMMING MANUAL 85
TROUBLESHOOTING
FAILURE 11: FILL FAILURE
Failure 11 occurs when the water level has not reached its target level in x minutes.
x = Max fill time, a value that can be programmed at the Initialization Menu.
ATTENTION! The rubber hose must be fixed with a flexible clamp on the electronic water level sensor.
DIAGNOSE:
1. Check if the programmed Max fill time in the
Initialization menu is acceptable.
If the water flow is very slow, increase the value for the
Max fill time. The default value is 10 minutes.
2. Check if the external water valves are open. If the water valves are closed: open the water inlet
valves.
3. Check if the water inlet valves are not
blocked by dirt.
If the water inlet valves are blocked by dirt: clean the
water inlet valves or replace the water inlet valves.
4. Check the coil of the water inlet valves. If the coil of the water inlet valve is electric open:
replace the coil or the complete water inlet valve.
5. Check the drain valve. If the drain valve is defective: replace the drain valve.
6. Check if the rubber hose (for measuring the
water level) is well mounted on the
electronic level sensor and on the drain valve.
If the hose is not well mounted: install the rubber hose
properly.
7. Check if the hose on the electronic sensor
is air tight.
If the air hose is not air tight: replace the air tube.
8. Check if the hose doesn’t contain water.
(siphon)
If the air tube contains water: remove the water and fix
the hose so that it doesn’t work as a siphon.
9. Check the continuity of the wiring. If the wiring is not continuous: repair the wiring.
10. Check the output relay that powers inlet
valves and the drain valve.
If the relay receives a command signal but is not
closed, replace the wash computer.
FAILURE 12: OVERFILL FAILURE
If the target water level is X units above the target level then failure message 12 will be displayed.
The fault message will not be generated when the user is advancing from a sequence with a high water level
to a sequence with a low water level.
X= „Max. level Overfill“, a value that can be programmed at the Initialization menu.
DIAGNOSE:
1. Check if the water inlet valves are broken. If the water inlet valves are broken: clean or replace
the water inlet valve diaphragms.
2. Check if the water pressure is too high. Lower the water pressure.
3. Check the output relay that powers the inlet
valve.
If the relay stays closed and the relay is broken,
replace the wash computer.
In Case of Steam Heating :
If the steam has not enough heating power (too low temperature), the machine will be filled with too much
water at the heating part. This will result in an increased water, energy and supply consumption.
It’s strongly recommended that the heating installation works with enough heating power.
A simple solution can also be to reduce the programmed target water level. As less steam will be required,
the normal water level should be reached. In the initialization menu it is also possible to adjust the alarm level
to avoid the error message. (= not recommended).
!
