FAILURE 13: HEATING FAILURE
If the heater elements are not functioning : message 13 will be displayed.
The message is generated when the temperature is not raising with 3°C in 10 minutes time.
DIAGNOSE:
1. Check if the heating contactor is activated. If the heating contactor is not activated: repair the
wiring or replace the contactor.
2. Check if the heating elements are heating. If the heating elements are not heating:
Repair the wiring or replace the defective heater elements.
3. Check if the temperature sensor is
functioning.
If the temperature sensor is defective: replace the
temperature sensor.
4. Check the output relay that powers the
heating contactor.
If the relay is broken, replace the wash computer.
FAILURE 14: HEATING TIME FAILURE
When after x minutes the target temperature is not reached (for a machine set as wait for heat):
Message 14 will be displayed.
x = the programmed Max heating time in the Initialization Menu.
DIAGNOSE:
1. Check if the programmed Max Heating time
in the Initialization menu is acceptable.
If the machine has a small heating capacity, increase
the value of the Max heating time.
The default is 60‘. (for machines with big heating
capacity)
2. Check if the heating resistors are heating. If the heating resistors are not heating:
Repair the wiring or replace the defective heater
elements.
3. Check the water temperature. If the hot water supply temperature is too low: increase
the temperature of the hot water.
4. Check if the temperature sensor
is functioning.
If the temperature sensor is defective: replace
the temperature sensor.
FAILURE 15: TOO HOT
When the water temperature is 15°C above the target temperature : message 15 will be displayed.
For evaluation of the problem, you can follow the water temperature of the bath on the display of the washing
machine by pressing the Service Button on the keypad.
DIAGNOSE:
1. Check if correct water inlet valves have
been programmed.
If only hot water inlet valves have been
programmed, and if the hot water supply
has a temperature value above
the programmed wash sequence value then
the temperature of the wash bath will be too high.
Choose the correct water inlet valves for the wash
sequence when you create or adjust the parameters of
the wash program.
Don't program only hot water inlet valves but also cold
ones!
