Prins VSI - LPG Hose Specifications

PAGE 16
076/19060100
Copyright © Prins Autogassystemen B.V. 2011
Renault
Clio 1.2 16v TCe100 2011
VERSION NR : C
16
LPG hoses
Hose
(Ø..mm)
From component
To component
Hose
length
(cm)
16
Reducer
Prins filter unit
50
11
Prins filter unit
VSI injector rail
30
5
Reducer overpressure
Y-piece
11
5
Reducer MAP connection
Y-piece
32
5
Y-piece
Inlet manifold coupling ( vacuum )
83
5
VSI injector 1
Inlet manifold coupling cyl.1
7,5
5
VSI injector 2
Inlet manifold coupling cyl.2
7,5
5
VSI injector 3
Inlet manifold coupling cyl.3
11
5
VSI injector 4
Inlet manifold coupling cyl.4
15
