Chapter 1 System Design
1-13
1.5 CANopen Board Type
*1 For supported models, refer to Pro-face’s support site “Otasuke Pro!” (http://www.pro-face.com/otasuke/).
You can connect to this site by clicking the GP-Pro EX’s [Help (H)] menu-[Connect to Support Site
“Otasuke Pro!” (C)] command.
*2 Up to seven EX modules can be connected next to the Hybrid Terminal Block (HTB).
GP Interface
(1) CANopen Interface
GP Unit
(1)
CANopen slave (Commercial type
*1
)
IO Cable
(Prepared by user)
Various types of I/O
equipment
Indicators, LEDs,
sensors, switches,
and so on
IO Cable
(Prepared by user)
Various types of I/O
equipment
Indicators, LEDs,
sensors, switches,
and so on
EX Module
*2
CANopen slave
(Hybrid Terminal Block)
