Display Specifications
Touch Panel Specifications
AGP-3200A AGP-3200T
Display Type Monochrome Amber/Red LCD TFT Color LCD
Resolution W320 X H240 pixels
Dot pitch W0.24mm[0.01in] X H0.24mm[0.01in]
Effective Display Area W78.8mm[3.10in] X H59.6mm[2.35in]
Color/Shade level
Black and White
(8 Shades)
256 Colors (No blink)
64 Colors (Enables blink feature)
Backlight
Amber/Red LED
(Not user replaceable.
When replacement is required,
contact your local GP distributor.)
White LED
(Not user replaceable.
When replacement is required,
contact your local GP distributor.)
Brightness control 16 levels of adjustment available via touch panel
Contrast Adjustment
8 levels of adjustment available via
touch panel
Not applicable
Display Service Life
MTBF value: 50,000hrs. (TYP)
(Backlight display service life is not
included.)
MTBF value: 40,000hrs. (TYP)
(Backlight display service life is not
included.)
Backlight Service Life
50,000hrs. or more
(at 25°C and continuous operation -
period until backlight brightness
decreases to 50%)
40,000hrs. or more
(at 25°C and continuous operation -
period until backlight brightness
decreases to 50%)
Language Fonts
Japanese: 6962 (JIS Standards 1 & 2)(including 607 non-kanji characters)
ANK: 158 (Korean fonts, Simplified Chinese and Taiwanese traditional Chi-
nese fonts are downloadable.
Text composition
Character Sizes
Standard font: 8X8, 8X16, 16X16 and 32X32 dot fonts
Stroke font: 6 to 127dot fonts
Font Sizes
Standard font: Width can be expanded up to 8 times.
Height can be expanded up to 8 times
*1
*1 The other font sizes can be set up by software.
Tex t
8 X 8 dots 40 Char. X 30 rows
8 X 16 dots 40 Char. X 15 rows
16 X 16 dots 20 Char. X 15 rows
32 X 32 dots 10 Char. X 7 rows
Type Resistive Film (analog)
Resolution 1024 X 1024
Service Life 1,000,000 times or more
