GP3000 Series Hardware Manual
4-32
4.3.2 Performance Specifications
Performance Specifications
AGP-3400∗ AGP-3450T
Internal Memory
*1
FLASH EPROM 8MB
Backup Data
SRAM 320KB
Used lithium battery for backup memory
Interface
Serial
Interface
COM1: RS232C/RS422/RS485
Asynchronous Transmission:
Data Length: 7 bit/8 bit
Parity: none, Odd or Even
Stop Bit: 1bit/2bit
Data transmission Speed: 2400 bps to 115.2 kbps
Connector: D-Sub 9-pin plug
COM2: RS422/RS485
Asynchronous Transmission
Data Length: 7 bit/8 bit
Parity: none, Odd or Even
Stop Bit: 1bit/2bit
Data transmission Speed: 2400 bps to 115.2 kbps
187.5 kbps (MPI)
Connector: D-Sub 9-pin socket
Ethernet
Interface
IEEE802.3u,10BASE-T/100BASE-TX
Connector: modular jack connector (RJ-45)
Expansion
Unit Interface
Connects the communication unit
USB Host
Interface
Conforms to USB1.1.(TYPE-A conn.) x 1
Power Supply Voltage: DC5V
± 5%
Output Current: 500mA(max.)
Communication Distance:5m(max.)
Function
Expansion
Memory
Interface
For Pro-face’s Function Expansion Memory mounting (on internal circuit board)
“8.6 Installation and Removal of Function Expansion Memory” (page 8-31)
CF Card
Interface
Compact Flash CF Card Slot (TYPE-II)
Video Input
Interface
-
NTSC: 59.9Hz
PAL: 50Hz
Connector: RCA 75
Ω
Sound Input
Interface
-
MIC input/LINE input
(Change with S/W)
Connector: MINI-JACK Φ3.5
Sound Output
Interface
Speaker Output
70mW(Rated Load: 8
Ω, Frequency: 1KHz)
Connector: Two piece type terminal block
AUX Input/
Output
Interface
Alarm Output, RUN Output, Buzzer Output
Rated Voltage: DC24V
Rated Current: 50mA
Remote Reset Input
Input Voltage: DC24V
Input Current: 6mA
Operating Voltage: (When ON) Min.: DC9V, (When OFF) Max. DC2.5V
Two piece type terminal block
Clock Accuracy
*2
±65 seconds/ month (at room temperature)
