Pro-face GP3000 Series - Serial Interface Item

GP3000 Series Hardware Manual
2-2
2.1 Accessories
All accessories listed here are produced by Pro-face.
2.1.1
Serial Interface Item
Product Name Model No. Description
RS-232C Cable CA3-CBL232/5M-01 (5m)
Connects Mitsubishi PLC A-Series (or
other host controller) to the AGP. (RS-
232C)
RS-422 Cable CA3-CBL422/5M-01 (5m)
Connects a host controller to the GP. (RS-
422)
Mitsubishi PLC Q-Series
Link Cable
CA3-CBLLNKMQ-01 (5m)
Connects Mitsubishi PLC Q-Series (or
other
host controller) to the AGP. (RS-232C)
Omron PLC SYSMAC Link
Cable
CA3-CBLSYS-01 (5m)
Connects Omron PLC SYSMAC Series
unit (or other host controller) to the AGP.
(RS-232C)
Mitsubishi PLC A-Series
Connection Cable
CA3-CBLA-01 (5m)
Connects Mitsubishi PLC A, QnA Series
programming console I/F to AGP.
(Simultaneous use of programming
console is not possible.)
Mitsubishi PLC Q-Series
Connection Cable
CA3-CBLQ-01 (5m)
Connects Mitsubishi PLC Q-Series
programming console I/F to AGP.
(Simultaneous use of programming
console is not possible.)
Mitsubishi PLC FX-Series
Connection Cable
CA3-CBLFX/1M-01 (1m)
CA3-CBLFX/5M-01 (5m)
Connects Mitsubishi PLC FX-Series
programming console I/F and AGP.
(Simultaneous use of programming
console is not possible.)
9-pin-to-25-pin RS-a232C
Conversion Cable
CA3-CBLCBT232-01
(0.2m)
Connects a standard RS-232C cable (GP
Connector,D-sub 25-pin) to the GP.
9-pin-to-25-pin RS-422
Conversion Cable
CA3-CBLCBT422-01
(0.2m)
Connects a standard RS-422 cable (GP
Connector,D-sub 25-pin) to the GP.
RS-422 Cable CA3-CBL422-01 (5m)
Connects a host controller to the GP. (RS-
422)
2 Port Adapter Cable CA3-MDCB11 (5m)
Connects Mitsubishi PLC to the GP using
2 port adapter II (RS-422).
Mitsubishi PLC A, QnA,
FX Series 2 Port Adapter II
GP070-MD11
Allows simultaneous use of an GP Series
unit and a Mitsubishi PLC A, QnA, FX
Series peripheral device.
Multi-Link Cable CA3-CBLMLT-01 (5m)
Connects a host controller to the GP for
multi-link (n:1) communication.
Terminal Block Conversion
Adapter
CA3-ADPTRM-01
Connects output from a serial interface
with an RS-422 terminal block.
COM Port Conversion
Adapter
CA3-ADPCOM-01
Connects optional RS-422 communication
items to AGP unit’s COM1 port. (AGP-3302
is compatible with COM1 and COM2 port.)
On-line adapter CA4-ADPONL-01
Terminal adapter in the case of performing
RS-422/RS-485 communication at COM2
port.
