Pro-face GP3000 Series - USB Host Interface

Chapter 2 Accessories
2-3
2.1.2 USB Host Interface
Siemens COM Port
Conversion Adapter
CA3-ADPSEI-01
Connects Siemens PLCs to the AGP. (for
RS-485 communication)
Siemens TTY Converter
Cable
CA6-CBLTTY/5M-01 (5m)
Connects Siemens PLC S5 Series to the
GP.
MPI Cable
ST03-A2B-MPI21-PFE
(3.5m)
GP3000-MPI21-PFE
(3.5m)
Connects a host controller to the GP for
MPI communication.
RS-232C Isolation Unit CA3-ISO232-01
Connects a host controller to the GP with
provides isolation.(RS-232C and RS-422
are switchable.)
RS-485 Isolation Unit CA3-ISO485-01
Connects a host controller to the GP with
provides isolation.(RS-422 and RS-485
are switchable.)
Product Name Model No. Description
USB Transfer Cable CA3-USBCB-01 (2m)
Downloads project data created with the
Screen Editor via the GP unit’s USB I/F.
USB Cable FP-US00 (5m) Connects a USB printer. (TYPE-B)
USB Front Cable CA5-USBEXT-01 (1m)
Extension cable attaching USB port to
front panel.
USB-Serial (RS-232C)
Conversion Cable
CA6-USB232-01(0.5m)
Cable for converting a GP unit's USB
interface into a serial interface (RS-232C).
Allows connection to modems
*1
or
barcode readers
*1
that support RS-232C.
Can be used to transfer project data
created with the Screen Editor via a serial
interface.
*2
*1 For supported models, refer to Pro-face’s support site “Otasuke Pro!” (http://www.pro-face.com/
otasuke/).
You can connect to this site by clicking the GP-Pro EX’s [Help (H)] menu-[Connect to Support
Site “Otasuke Pro!” (C)] command.
*2 Requires an RS-232C cable (prepared by user) for connection. For details regarding system
design, refer to "Edit Mode Peripherals" (page 1-7) if using models except for AGP-3302*;
refer to "Edit Mode Peripherals" (page 1-11) if using AGP-3302*.
For instructions on how to connect between USB-Serial (RS-232C) Conversion Cable and your
PC, always refer to the "GP-Pro EX Reference Manual -> Transferring Projects and Data -> COM
Transfer Connections".
