Information Symbols
This manual uses the following icons:
GP3000 Series Model Name Indication
Model name
A G P 3
* **
-
*
1 -
***
-
****
Indicates a warning or a product limitation. Be sure to follow the instructions given with
this icon to ensure the safe operation of the GP.
Screen Editor Indicates the GP-Pro EX software.
PLC Abbreviation for Programmable Logic Controller.
Logic program Indicates a ladder program created with the GP-Pro Ex.
* Indicates useful or important supplemental information.
Contains additional or useful information.
Indicates pages containing related information.
A
2 GP-3200 series (3.8-inch): QVGA (320 x 240 dots)
3 GP-3300 series (5.7-inch): QVGA (320 x 240 dots), VGA (640 x 480 dots)
*1
4 GP-3400 series (7.5-inch): VGA (640 x 480 dots)
5 GP-3500 series (10.4-inch)
*2
: VGA (640 x 480 dots),SVGA(800 x 600 dots)
*3
6 GP-3600 series (12.1-inch): SVGA (800 x 600 dots)
7 GP-3700 series (15-inch): XGA (1024 x 768 dots)
B
00
Standard machine
10
*1*3
01
Low-cost machine
02
50
Multimedia machine
60
*1*3
C
A Monochrome amber/red mode LCD
B Monochrome blue mode LCD
L Monochrome LCD
S STN color LCD
T TFT color LCD
U TFT Color LCD (Ultra luminance)
D
AF AC type power supply is used.
D24 DC type power supply is used.
E
Omitted Standard type
D81K DIO board type (sink type)
D81C DIO board type (source type)
FN1M FLEX NETWORK board type
CA1M CANopen board type
*1 AGP-3310T/3360T only.
*2 The AGP-3500L and The AGP-3500S have the same dimensions as a 12.1-inch display unit.
*3 AGP-3510T/3560T only.
