Pro-face GP3000 Series - General Specifications; GP-3300 Series

GP3000 Series Hardware Manual
4-12
4.2 GP-3300 Series
4.2.1 General Specifications
Electrical Specifications
Environmental Specifications
AGP-3300 ∗ /3301 ∗ /3310T/3360T AGP-3302∗
Power Supply
Input Voltage DC24V
Rated Voltage DC19.2 to 28.8V
Allowable Voltage Drop 5ms (max.) 10ms (max.)
Power Consumption 26W (max.) 18W (max.)
In-Rush Current 30A (max.)
Voltage Endurance
AC1000V 20mA for 1 minute
(between charging and FG terminals)
Insulation Resistance
DC500V 10MΩ (min.)
(between charging and FG terminals)
Physical
Surrounding Air
Temperature
0 to 50°C
*1
*1 When using Monochrome / STN Color LCD model in an environment where the
temperature becomes or exceeds 40°C for an extended period of time, the screen contrast
level may decrease from its original level of brightness.
Storage Temperature -20 to +60°C
Ambient Humidity
10 to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Storage Humidity
10 to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Dust 0.1mg/m
3
and below (non-conductive levels)
Pollution Degree For use in Pollution Degree 2 environment
Atmosphere Free of corrosive gases
Air Pressure Vibration
Resistance (altitude
range)
800 to 1114hPa
(2,000 meters above sea-level and below)
Mechanical
Vibration Resistance
IEC61131-2 compliant
5 to 9Hz single-amplitude 3.5mm [0.14 in.]
9 to 150Hz constant-accelerated velocity 9.8m/s
2
X,Y,Z directions for 10 cycle (100 minute)
Concussion Resistance
IEC61131-2 compliant
(147m/s
2
X,Y,Z directions for 3 time)
Electrical
Noise Immunity
Noise Voltage: 1000V
P-P
Pulse Duration: 1µs
Rise Time: 1ns
(via noise simulator)
Electrostatic Discharge
Immunity
6kV (complies with EN 61000-4-2 Level 3)
