1-4. Specifications
Model
3310F
3311F
3312F
Power
150W 300W 300W
Current
30A 60A 12A
Voltage
60V 60V 250V
Min. Operating Voltage
0.6V @ 30A 0.6V @60A 1V @ 12A
Protections
Over Power Protection(OPP)
105% 105% 105%
Over Current Protection(OCP)
105% 105% 105%
Over Voltage Protection(OVP)
105% 105% 105%
Over Temp Protection(OTP)
YES YES YES
Constant Current Mode
Range
0 ~ 3A 0 ~ 30A 0 ~ 6A 0 ~ 60A 0 ~ 1.2A 0 ~ 12A
Resolution
0.05mA 0.5mA 0.1mA 1mA 0.02mA 0.2mA
Accuracy
± 0.05% of ( setting + Range)
Constant Resistance Mode
Range
2 ~120KΩ 0.02Ω ~ 2Ω 1Ω ~ 60 KΩ 0.0083Ω ~ 1Ω 25Ω ~ 1500KΩ 0.08Ω ~ 25Ω
Resolution
0.00833mS 0.033mΩ 0.0166mS 0.0166mΩ 0.00066mS 0.4166mΩ
Accuracy
± 0.2% of (Setting + Range)
Constant Voltage Mode
Range
0 ~ 6V 0 ~ 60V 0 ~ 6V 0 ~ 60V 0 ~ 30V 0 ~ 250V
Resolution
0.0001V 0.001V 0.0001V 0.001V 0.001V 0.01V
Accuracy
± 0.025% of (Setting + Range)
Constant Power Mode
Range
0 ~ 15W 0 ~ 150W 0 ~ 30W 0 ~ 300W 0 ~ 30W 0 ~ 300W
Resolution
0.00025W 0.0025W 0.0005W 0.005W 0.0005W 0.005W
Accuracy
± 0.1% of (Setting + Range)
MPPT Mode
Algorithm
P & O
Load mode
CV
P&O interval
1000ms ~ 60000ms
Dynamic Mode
Timing
Thigh & Tlow 0.050~9.999 / 99.99 / 999.9 / 9999mS
Resolution 0.001 / 0.01 / 0.1 / 1mS
Slew rate 2.0 ~ 125mA/uS 20 ~ 1250mA/uS 4 ~ 250mA/uS 40 ~ 2500mA/uS 0.8 ~ 50mA/uS 8 ~ 500mA/uS
Accuracy ± (5% of Setting) ±10uS
Measurement
Voltage Read Back
Range (5 Digital) 6V 60V 6V 60V 30V 250V
Resolution 0.0001V 0.001V 0.0001V 0.001V 0.001V 0.01V
Accuracy ± 0.025% of (Reading + Range)
Current Read Back
Range (5 Digital) 3A 30A 6A 60A 1.2A 12A
Resolution 0.0001A 0.001A 0.0001A 0.001A 0.00002A 0.0002A
Accuracy ± 0.05% of (Reading + Range)
Current Monitor FULL SCALE 10V
Accuracy 0.5% of (Setting + Range)
Current Programming Input FULL SCALE 10V
Programmable Short BUILT-IN
Load ON Voltage 0.1 ~ 25V 0.1 ~ 25V 0.2 ~ 50V
Accuracy 1% of (Setting + Range)
Load OFF Voltage 0 ~ 25V 0 ~ 25V 0 ~ 50V
Accuracy 0.025% of (Setting + Range)
Typical Short Resistance 0.02 Ω 0.0083 Ω 0.08 Ω
Maximum Short Current 30 A 60 A 12 A
