3-3 Initial setting of 3310F series load module
The following tables detail the initial settings of the 3310F series of Load Modules when
Shipped from the factory.
Item
Initial value
Item
Initial value
CC L+Preset
0.0000 A
LIMIT
V_Hi
60.000 V
CC H+Preset
0.0000 A
V_Lo
0.000 V
CR H+Preset
120000 Ω
I_Hi
30.000 A
CR L+Preset
120000 Ω
I_Lo
0.000 A
CV H+Preset
60.000 V
W_Hi
150.00 W
CV L+Preset
60.000 V
W_Lo
0.000 W
CP L+Preset
0.000W
CONFIG
SENSE
Auto
CP H+Preset
0.000W
LD-ON
1.0 V
DYN
T HI
0.050 mS
LD-OFF
0.500 V
T L0
0.050 mS
POLAR+LOAD
RISE
125.0mA/uS
MPPT
2000ms
FALL
125.0mA/uS
AVG
1
SHORT
Disable
OPP
Disable
OCP
Disable
Table 3-1 3310F initialize
Item
Initial value
Item
Initial value
CC L+Preset
0.0000 A
LIMIT
V_Hi
60.000 V
CC H+Preset
0.0000 A
V_Lo
0.000 V
CR H+Preset
60000 Ω
I_Hi
60.000 A
CR L+Preset
60000Ω
I_Lo
0.000 A
CV H+Preset
60.000 V
W_Hi
300.00 W
CV L+Preset
60.000 V
W_Lo
0.00 W
CP L+Preset
0.000W
CONFIG
SENSE
Auto
CP H+Preset
0.000W
LD-ON
1.0 V
DYN
T HI
0.050ms
LD-OFF
0.500 V
T L0
0.050ms
POLAR+LOAD
RISE
250mA/us
MPPT
2000ms
FALL
250mA/us
AVG
1
SHORT
Disable
OPP
Disable
OCP
Disable
Table 3-2 3311F initialize
